Fujitsu Ceiling Type Design & Technical Manual

¢
Heating capacity (Twin)

Cassette type
Model: AUYG45LRLA × 2
AFR
m
3
/h
3,800
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.58 12.47 6.71 12.16 6.85 11.86 6.99 11.56 7.11
-15 -16 19.57 7.59 19.11 7.75 18.64 7.91 18.18 8.07 17.72 8.22
-10 -11 22.81 8.07 22.27 8.23 21.73 8.40 21.19 8.57 20.65 8.74
-5 -7 25.33 8.41 24.73 8.58 24.12 8.76 23.52 8.93 22.92 9.11
0 -2 27.31 8.50 26.66 8.67 26.00 8.85 25.35 9.03 24.71 9.19
5 3 30.86 8.52 30.12 8.70 29.39 8.87 28.65 9.03 27.92 9.17
7 6 31.19 8.52 30.44 8.70 29.70 8.88 28.96 9.06 28.22 9.18
10 8 32.64 8.47 31.86 8.64 31.08 8.82 30.29 8.99 29.53 9.18
15 10 33.88 8.46 33.07 8.63 32.26 8.81 31.45 9.00 30.65 9.12
20 15 30.48 7.39 29.75 7.53 29.02 7.69 28.30 7.85 27.57 7.95
24 18 31.16 7.35 30.42 7.49 29.67 7.65 28.93 7.81 28.20 7.91

Duct type
Model: ARYG45LMLA × 2
AFR
m
3
/h
4,200
Indoor temperature
°CDB 16 18 20 22 27
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.92 12.47 7.06 12.16 7.21 11.86 7.35 11.56 7.48
-15 -16 19.57 7.98 19.11 8.15 18.64 8.32 18.18 8.48 17.72 8.65
-10 -11 22.81 8.48 22.27 8.66 21.73 8.83 21.19 9.01 20.65 9.18
-5 -7 25.33 8.84 24.73 9.03 24.12 9.21 23.52 9.39 22.92 9.58
0 -2 27.31 8.93 26.66 9.12 26.00 9.31 25.35 9.49 24.71 9.66
5 3 30.86 8.96 30.12 9.14 29.39 9.33 28.65 9.50 27.92 9.64
7 6 31.19 8.96 30.44 9.15 29.70 9.34 28.96 9.52 28.22 9.65
10 8 32.64 8.90 31.86 9.08 31.08 9.28 30.29 9.45 29.53 9.65
15 10 33.88 8.90 33.07 9.07 32.26 9.27 31.45 9.46 30.65 9.59
20 15 30.48 7.77 29.75 7.91 29.02 8.08 28.30 8.25 27.57 8.36
24 18 31.16 7.72 30.42 7.87 29.67 8.04 28.93 8.21 28.20 8.32

Ceiling type
Model: ABYG45LRTA × 2
AFR
m
3
/h
4,200
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC TC
kW kW kW kW kW kW
-20 -21 12.77 6.58 12.47 6.71 12.16 6.85 11.86 6.99 11.56 7.11
-15 -16 19.57 7.59 19.11 7.75 18.64 7.91 18.18 8.07 17.72 8.22
-10 -11 22.81 8.07 22.27 8.23 21.73 8.40 21.19 8.57 20.65 8.74
-5 -7 25.33 8.41 24.73 8.58 24.12 8.76 23.52 8.93 22.92 9.11
0 -2 27.31 8.50 26.66 8.67 26.00 8.85 25.35 9.03 24.71 9.19
5 3 30.86 8.52 30.12 8.70 29.39 8.87 28.65 9.03 27.92 9.17
7 6 31.19 8.52 30.44 8.70 29.70 8.88 28.96 9.06 28.22 9.18
10 8 32.64 8.47 31.86 8.64 31.08 8.82 30.29 8.99 29.53 9.18
15 10 33.88 8.46 33.07 8.63 32.26 8.81 31.45 9.00 30.65 9.12
20 15 30.48 7.39 29.75 7.53 29.02 7.69 28.30 7.85 27.57 7.95
24 18 31.16 7.35 30.42 7.49 29.67 7.65 28.93 7.81 28.20 7.91
- 160 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
