D323x-S
V0.9
Page
60
of
65
http://www
.fujitsu.com/fts/product
s/computing/pc/accessori
es/mainboards
m
ainboards
Miscellaneous
Syst
em
W
atchdog (WD)
How to handle the different watc
hdog levels
BIOS POST W
atchdog
o
No
user interaction possib
le
–
POST Watch
dog is alwa
ys enabled!
BIOS Boot W
atchdog
o
Set W
atchdog in BIOS Se
tup
0 = WD disabled
1
–
255 = WD enabled (ti
meout = 1
–
255 minutes
)
59
61
