System Monitoring
4.6 SilentFanConfigManager – Customize System Monitoring Settings
Windows-based System Management Configuration Tool
ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D323x-S/IndustrialTools_D323x-S/SilentFanConfig-Manager/
1. Windows-based configuration tool (SilentFanConfig) to create customized system monitoring settings like minimum fan speed and
temperature sensor influence. These customized settings are stored in a specific “SMCO” flash file.
2. DOS-based tool “SMCO” to flash the customized system monitoring settings (SMCO file) to the system BIOS of the target unit.
SilentFanConfig-Tool: SMCO-Tool SilentFanConfig-Tool +
Create specific system SMCO Flash File Flash SMCO file to SMCO-Tool =
monitoring settings mainboard BIOS SilentFanConfigManager
(any Windows-based PC) (each unit in production)
Note: New settings are written permanently to system BIOS.
Any BIOS update will not reset the new settings
SilentFanConfig V1.70.1 or higher required for D323x-S, V1.71.0 or higher for D3243-S
Please see documentation in ZIP file (link below) for further details.
ftp://ftp.ts.fujitsu.com/pub/Mainboard-OEM-Sales/Products/Mainboards/Industrial&ExtendedLifetime/D323x-S/IndustrialTools_D323x-S/SilentFanConfig-Manager/
