Pin Signal Function
1 VCC33 Power Supply 3.3 V for XXSvideo-D
2 VCC33 Power Supply 3.3 V for XXSvideo-D
3 MEM_XCS4 Chip Select 4 for Flash Memory
4 VCC33 Power Supply 3.3 V for XXSvideo-D
5 CPU_D15 Data
6 VCC33 Power Supply 3.3 V for XXSvideo-D
7 CPU_A1 Address
8 GND Ground
9 CPU_A3 Address
10 CPU_D0 Data
11 CPU_A4 Address
12 CPU_D3 Data
13 CPU_A7 Address
14 CPU_D4 Data
15 CPU_A8 Address
16 CPU_D7 Data
17 CPU_A11 Address
18 CPU_D8 Data
19 CPU_A12 Address
20 CPU_D11 Data
21 CPU_A15 Address
22 CPU_D12 Data
23 CPU_A16 Address
24 CPU_D14 Data
25 CPU_A19 Address
26 CPU_D1 Data
27 CPU_A20 Address
28 CPU_D2 Data
29 CPU_A23 Address
30 CPU_D5 Data
31 MEM_XWR1 Write Strobe
32 CPU_D6 Data
33 MEM_XRD Read Strobe
34 CPU_D9 Data
