Following table shows the assignment from pins, signals and function of connector X401 I/O
signals side:
Pin Signal Function
1 VCC33 Power Supply 3.3 V for XXSvideo
2 VCC33 Power Supply 3.3 V for XXSvideo
3 VCC33 Power Supply 3.3 V for XXSvideo
4 VCC33 Power Supply 3.3 V for XXSvideo
5 GND Ground
6 GND Ground
7 GND Ground
8 GND Ground
9 INT_A0 INT_A0
10 I2C1 I2C_SDA0
11 INT_A1 INT_A1
12 I2C0 I2C_SCL0
13 I2C3 I2C_SDA1
14 I2C2 I2C_SCL1
15 INT_A3 INT_A3
16 SD_CARD7 SD_XMCD
17 INT_A2 INT_A2
18 SD_CARD6 SD_WP
19 SD_CARD5 SD_DAT3
20 SD_CARD3 SD_DAT1
21 SD_CARD4 SD_DAT2
22 SD_CARD2 SD_DAT0
23 SD_CARD0 SD_CLK
24 UART5 UART_SOUT1
25 SD_CARD1 SD_CMD
26 UART4 UART_SIN1
27 UART6 UART_SIN2
28 UART2 UART_CTS0#
29 UART7 UART_SOUT2
30 UART0 UART_SIN0
31 ADC5 AD_VRL1
32 UART3 UART_RTS0#
33 ADC7 AD_VR1
