Developer’s Manual for EVB JADE-D Interface Board
Summary
This manual provides detailed technical information for system architects, hardware and
software developers, who work with the EVB JADE-D Interface board version PA 4 for
evaluation and development purpose.
Enclosures
None.
Product Information
A JADE Evaluation board was developed to demonstrate the versatile features from the JADE
and its interfaces.
The JADE together with DDR SDRAM and Flash memory is implemented as module which is
called XXSvideo and can be plugged on the JADE Evaluation board.
Now also a module with the JADE-D is available. It is called XXSvideo-D.
For using the XXSvideo-D module with the JADE Evaluation board the EVB JADE-D
Interface board was developed.
