Preliminary
4(45)
Prepared Document Number
Manfred Ortmann
Approved Checked Date Revision Storage
2009-10-05 PA 4.2 Mycable01
Revision History
Revision Date Sign Description
PA2.1 2009-03-02 mo Document setup
PA2.2 2009-03-09 mo Pinning of APIX signals
PA3.1 2009-04-23 mo Documentation after finishing PCB
PA3.2 2009-05-15 mo Pin table of X804 added
PA3.3 2009-07-06 mo Pictures added
PA4.1 2009-08-14 mo PCB revision PA4
video connector X804
APIX connector X802
PA4.2 2009-10-05 mo Picture change
Contact Information
mycable GmbH
Michael Carstens-Behrens
( hardware and commercial )
Email mcb@mycable.de
Tel. +49 4321 55956 55
mycable GmbH
Carsten Schneider ( Software )
Email cs@mycable.de
mycable GmbH
Manfred Ortmann ( Hardware )
Email mo@mycable.de
