Fujitsu EVB JADE-­D - Page 38

Preliminary
38(45)
Prepared Document Number
Manfred Ortmann
Approved Checked Date Revision Storage
2009-10-05 PA 4.2 Mycable01
Pin Signal Function
12 DISP_P_R_6 DOUTG0_4
13 DISP_N_R_5 DOUTG0_3
14 DISP_P_R_5 DOUTG0_2
15 GND
16 DISP_SYNC_R_3 DCLKP
17 DISP_SYNC_R_4 DCLKN
18 NC Testpoint 802
19 NC Testpoint 800
20 DISP_P_R_3 DOUTR0_6
21 DISP_N_R_3
22 DISP_P_R_2 DOUTR0_4
23 DISP_N_R_2
24 DISP_P_R_1 DOUTR0_2
25 DISP_N_R_1
26 DISP_P_R_8
27 DISP_N_R_8
28 DISP_P_R_4
29 DISP_N_R_4
30 DISP_P_R_0
31 DISP_N_R_0
32 TSG_R_4
33 TSG_R_5
34 TSG_R_6
35 TSG_R_7
36 TSG_R_8
37 TSG_R_9
38 TSG_R_10
39 TSG_R_11
40 GND
41 TSG_R_12
