Pin Signal Function
42 GND
43 DISP_SYNC_R_0 HSYNC0
44 DISP_SYNC_R_1 VSYNC0
45 DISP_SYNC_R_2 GVO0
46 Testpoint 803
47 GND Ground
48 Testpoint 804
49 DISP_SYNC_R_5 DE0
50 VCC33 + 3.3 V output voltage
Tab. 2-9: Pin assignment of connector X804
