Fujitsu plasmavision Service Manual

SPECIFICATIONS
EN55022 A1/A2
Class B
EN61000-3-2, 1995
EN61000-3-3, 1995
EN55024 1998
EN61000-4-2, 1995
EN61000-4-3, 1996
EN61000-4-4, 1995
EN61000-4-5, 1995
EN61000-4-6, 1996
EN61000-4-8, 1993
EN61000-4-11, 1994
100-240V, 50/60Hz
Current drain 3.5A
Display panel
Power requirement
Screen size 92.1 (W) x 51.8 (H) [cm]
36.3 (W) x 20.4 (H) [inch]
Aspect ratio 16 : 9
Number of pixels 852 (H) x 480 (V) pixels
Pixel pitch 1.08mm x 1.08mm
Contrast ratio PDS4233/4234 1500 : 1 (typ.)
Brightness 700 cd/m
2
(typ.)
Viewing angle Max. 160 degrees
Input Terminals
Video input BNC connector
1.0V
P-P /75
S video input S terminal
Y signal:1.0V
P-P /75
C signal:0.286V
P-P /75
Component Three BNC terminals
video input Y : 1V
P-P /75
P
b /B-Y: 0.7V P-P
Pr /R-Y: 0.7V P-P
RGB 2 input mD-sub:15pin (3 row type)
Video : 0.7V
P-P
SYNC signal : TTL level
RGB 3 input BNC terminal x 5
R: 0.7V
P-P
G: 0.7V P-P
B: 0.7V P-P
H: TTL level or 0.3VP-P
V: TTL level or 0.3VP-P
User set mode 8 memories (each RGB1,2)
Display frequency Horizontal :15.63 to 80.0MHz
Vertical : 50.0 to 120Hz
Dot clock:50MHz Max
XGA 68MHz Max
RS-232C D-sub 9 pin terminal
Color system
NTSC/PAL/SECAM/N-PAL/M-PAL
/4.43NTSC/PAL60
Display colors 16.7 million (256 each for R.G.B.)
2 pin terminals(one system)
Audio input
500mVrms/22k
Effective max.
Level terminal 9W+9W (L/R), 8
output
Dimensions Width : 103.5cm (40.7 inch)
Height: 64.0cm (25.2 inch)
Depth : 8.5 cm ( 3.3 inch)
Net weight 28.5kg
Environment (Operating)
Temperature 0 to 40 C
Relative humidity 20 to 80%
Pressure 720 to 1,100 hPa
Accessories User's manual
Remote controller
Batteries (Type AA x 2)
Power cord
Ferrite core (2)
Options
Stand P-42TT33
Wall mounting unit
P-42WB12 installation angle
Horizontal 0 to 15
Vertical 0 to 5
Ceiling mounting unit P-42CT11 installation angle
Available 0 to 15
Standards
PDS4233W/E-H PDS4234W/E-S
AS
Safety : IEC950 A1/A2/A3/A4 IEC950 A1/A2/A3/A4
EMC : AS/NZS 3548 AS/NZS 3548
EN60950 1992
A1 1993
A2 1993
A3 1995
A4 1997
CE
Safety: EN60950 1992
A1 1993
A2 1993
A3 1995
A4 1997
UL,CSA
Safety: UL1950 UL1950
CSA C22.2 No.950 CSA C22.2 No.950
EMC: FCC Part15 Class A FCC Part15 Class B
ICES-003 Class A ICES-003 Class B
EMC : EN55022 A1/A2
Class A
EN61000-3-2,1995
EN61000-3-3,1995
EN55024 1998
EN61000-4-2,1995
EN61000-4-3,1996
EN61000-4-4,1995
EN61000-4-5,1995
EN61000-4-6,1996
EN61000-4-8,1993
EN61000-4-11,1994
RGB 1 input
DVI-D terminal
/75
/75
/75
/75
/75
/75
/75
/75
- 4 -

Fujitsu plasmavision Specifications

General

Brand	Fujitsu
Model	plasmavision
Category	Monitor
Language	English
