16 Operating Manual BX920 S2
Technical data
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-5777-001.fm
Certification
Mechanical specifications
Weight
Max. max. 5,3 kg (depending on the configuration).
Ambient conditions
Condensation during operation must be avoided!
Product safety
approved with the PRIMERGY BX900 basic system
Global CB
Germany GS, CE
USA/Canada CSA
US
/CSA
C
Japan VCCI
China/Taiwan BSMI
Width 45 mm
Depth 508 mm
Height 210,5 mm (1 bay in the system unit)
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 5 ºC .... 35 ºC
Transport (2K2) -20 °C .... 60 °C
Humidity 10%...85% (non condensing)
