BX920 S2 Operating Manual 33
Installing the Server Blade in the system unit
Removing the dummy module
Any unused slots on the front of the system unit are fitted with appropriate
dummy modules to comply with electromagnetic compatibility (EMC)
regulations and to ensure sufficient cooling of the system components.
To add a server blade, you must first remove a dummy module from the relevant
slot.
Figure 2: Removing the Server Blade dummy module
Ê Pull the handle of the dummy module (see arrow) up to unlock the dummy
module.
Ê Pull the dummy module out of the slot.
V CAUTION!
Keep the dummy module for future use. If you remove a server blade and
do not replace it with a new one, you must install a dummy module to
comply with the regulations regarding electromagnetic compatibility and
to ensure sufficient cooling of the system components.
