40 Operating Manual BX920 S2
Control and display elements
© cognitas. Gesellschft für Technik-Dokumentation mbH 2010 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-5781-001.fm
Control elements
LEDs on the control panel
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button.
When the system is operating, pressing the On/Off button will
switch off the system.
V CAUTION!
Risk of loss of data!
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
ID ID button
Lights up (blue) on the front and on the rear of the system unit when
the ID button is pressed. The two ID indicators are synchronized.
Power indicator (two-color)
Does not light up if no line voltage is present.
Lights red when the server is switched off but line voltage is
present.
Lights orange (red and green at the same time) to indicate a power
supply error.
Glows green when the server is switched on.
Flashes green when the server has been switched on and is in
standby mode.
