Fujitsu Primergy RX100 S4 - SATA backplane (only hot-plug variant)

34 Service Supplement RX100 S4
Board layout Appendix
5.1.2 SATA backplane (only hot-plug variant)
Part number: S26361-D2536-A10
1 Connector power cable
2 Connector SATA cable for hard disk 1
3 Connector I
2
C cable
4 Connector SATA cable for hard disk 2
5 Connector SATA LED cable
5
4
3
2
1
