Fujitsu PRIMERGY TX100 S2 - Page 63

TX100 S2 Options Guide 63
Appendix Cabling
Figure 38: Power cables, parallel port and fans
Power SAS
FDD
Data
Legend:
USB
I
2
C
SATA
Parallel/Seriell
Adapter
Intrusion
PSU E551-
V70
Front fan
Rear fan
Front panel
USB front
Optical Drive (Top)
Optical Drive (Bottom)
HDD 1 HDD 3
HDD 2
HDD 4
T26139-Y3942-V221
UFM
Front
----- Backup
AUX
64 2
53 1
P1
P9
P8
P4
P3
P6
P7
P2 not used
T26139-Y3701-V147
T26139-Y3894-V513
USB DAT/RDX Drive (Bottom)
T26139-Y3942-V1
alternative
