18 Operating Manual
TX1310 M1
Functional overview
Interfaces
Onboard or integrated controllers
Slots
I Configuration options may vary depending on base unit (see "Different
versions for TX1310 M1" on page 10).
Drive bays
USB connectors USB 3.0 (2x front, 2x rear), USB 2.0 (4x rear), USB
3.0 (1x internal) for backup drives
Graphics (15-pin) 1x VGA
Serial 1 (9-pin) 1x serial RS-232
LAN / Ethernet (RJ-45) 2x Gbit/s Ethernet
Serial ATA total 6
RAID Controller RAID level 0, 1, 10
SATA Controller Embedded in Intel
®
Chipset C226
®
LAN Controller Single chip GbE Ethernet controller Intel® i210
onboard,
Single chip GbE Ethernet PHY Intel® i217LM,
2 x 10/100/1000 Mbit/s, PXE-Boot by LAN via PXE-
Server, Teaming supported
Trusted Platform
Module (TPM)
Infineon / 1.2 (option)
PCI-Express Gen3 x8 2x (mechanically x8) both notched
PCI-Express Gen2 x4 1x (mechanically x8)
PCI-Express Gen2 x1 1x (mechanical x4)
Hard disk bay
configuration
4x 3,5-inch SATA
Accessible drives 2 (one bay is occupied by DVD/DVD-RW, 5.25-inch)
