Fujitsu PRIMERGY TX1320 M1 User Manual

28 Operating Manual TX1320 M1
Functional overview
Noise level (depending on the configuration)
Electrical values
SATA systems SAS systems
Sound power level L
WAd
(ISO 9296)
3.7 B (standby)
3.7 B (operation)
4.9 B (standby)
5.0 B (operation)
Sound pressure level at
adjacent workstation
L
pAm
(ISO 9296)
22 dB (A) (standby)
23 dB (A) (operation)
33 dB (A) (standby)
35 dB (A) (operation)
Power supply
configuration
1x standard power supply
Max. output 250 W
Rated voltage range 100 - 240 V
Rated frequency range 47 Hz - 63 Hz
Rated current max. 6.0 A – 3.0 A (100 V / 240 V)

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
