Fujitsu PRIMERGY TX1320 M1 User Manual

TX1320 M1 Operating Manual 63
Starting up and operation
6.3 Controls and indicators
6.3.1 Front of server
Figure 13: Front side (indicators and controls)
1 HDD error indicator 9 Global Error indicator
2 PSU error indicator 10 HDD / SSD activity indicator
3 Temperature error indicator 11 Power-on indicator
4 CPU error indicator 12 On/Off button
5 Memory error indicator 13 NMI button
6 Fan error indicator 14 Reset button
7 ID indicator 15 ID button
8 CSS indicator 16 2 USB connectors

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
