Fujitsu PRIMERGY TX1320 M1 User Manual

24 Operating Manual TX1320 M1
Functional overview
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
Processor
Memory Modules Configuration
Interfaces
System board type D3239
Chipset Intel
®
C224
Processor quantity and
type
1x Intel
®
Xeon
®
E3-1200 v3 (quad-core), Celeron
®
,
Pentium
®
, Core
®
i3
Memory slots 4
Memory slot type UDIMM (DDR3)
Memory capacity
(min. - max.)
2 GB - 32 GB
Memory protection ECC
Memory notes 1600 MHz memory modules with 2, 4, or 8 GB
USB connectors 7x USB 2.0 (UHCI) with 480 MBit/s (4x external at
the rear, 2x external at the front, 1x internal for UFM,
no USB wake-up)
3x USB 3.0 (UHCI) with 5 GBit/s (2x external at the
rear, 1x internal for backup device)
Graphics (15-pin) 1 x VGA
Serial 1 (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ-45) 2 x Gbit/s Ethernet

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
