TX1320 M1 Operating Manual 25
Functional overview
Onboard or integrated controllers
Slots
Service LAN (RJ45) 1 x dedicated service LAN port for iRMC S4
(10/100/1000 Mbit/s) Service LAN traffic can be
switched to shared onboard Gbit LAN port
RAID Controller Modular RAID 0/1 controller with "Integrated
Mirroring Enhanced" (SAS IME) for SAS1.0.
RAID levels 0, 1 and 1E are supported for internal
hard disk drive configurations.
Modular RAID 0/1 controller with "MegaRAID
functionality" (SAS MegaRAID) for SAS1.0 and
SAS2.0.
RAID levels 0, 1,10 and 1E are supported for internal
hard disk drive configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (SAS MegaRAID) for SAS1.0 and
SAS2.0. RAID levels 0, 1, 10, 1E, 5, 50, 6 and 60 are
supported for internal hard disk drive configurations.
SATA Controller A 6-port SATA controller is integrated on the system
board; up to four SATA hard disk drives can be
connected to the controller. The LSI Embedded
MegaRAID software (SATA Software RAID)
supports RAID levels 0, 1 and 10.
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4, 32 MB attached memory incl. graphics
controller), IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / 1.2 (option)
PCI-Express x8 Gen3 2x
PCI-Express x4 Gen2 1x (mechanically x8)
PCI-Express x1 Gen2 1x (mechanically x4)
Slot notes in SAS configuration 1x PCI-Express occupied by
modular RAID controller

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
