Fujitsu PRIMERGY TX1320 M1 User Manual

26 Operating Manual TX1320 M1
Functional overview
Drive bays
Operating Panel
Hard disk bay
configuration
6x 2.5-inch hot-plug SAS/SATA or 2x 3.5-inch non
hot-plug SATA
Accessible drive bays 1x 3.5/1.6-inch for backup devices; 1x 5.25/0.5-inch
for CD-RW/DVD
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/off switch
NMI button
Reset button
ID button
Status LEDs System status (orange / yellow)
Identification (blue)
Hard disks access (green)
Power (orange / green / yellow)
CSS (yellow)
HDD (orange)
PSU (orange)
TEMP (orange)
CPU (orange)
MEM (orange)
FAN (orange)
Status LED at system
rear side:
System status (orange / yellow)
Identification (blue)
LAN connection (green)
LAN speed (green / yellow)
CSS (yellow)

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
