Fujitsu PRIMERGY TX1320 M4 - Controllers

TX1320 M4 Operating Manual 95
Technical data
Controllers
RAID controller PSAS CP400i with "Integrated RAID" (IR)
RAID levels 0 and 1 are supported for internal HDD
configurations.
Modular RAID controller (based on LSI SAS3108)
SAS/SATA HDD/SSD up to 12 Gbit/s SAS, 6 Gbit/s
SATA, 8 ports internal/external
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
1/2/4 GB cache, optional FBU
Modular RAID controller (based on LSI SAS3508)
SAS/SATA/PCIe HDD/SSD up to 12 Gbit/s SAS,
6 Gbit/s SATA, 8 Gbit/s PCIE, 8 ports internal
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
2 GB cache, optional FBU
Modular RAID controller (based on LSI SAS3516)
SAS/SATA/PCIe HDD/SSD up to 12 Gbit/s SAS,
6 Gbit/s SATA, 8 Gbit/s PCIE, 16 ports internal /
8 ports external
RAID level: 0, 1, 1E, 10, 5, 50, 6, 60
4/8 GB cache, optional FBU
SATA controller 1x SATA controller integrated on the system board;
up to four SATA HDDs/SSDs can be connected to
the controller. The LSI Embedded MegaRAID
software (Software RAID) supports RAID levels 0, 1,
10.
1x single SATA3 connector for ODD
2x M.2 connector with support for SATA and PCIe
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4/S5), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon / separate module; TCG V2.0 compliant,
SPI support (option)
