96 Operating Manual TX1320 M4
Slots - standard
Drive bays
Dimension/Weight
Ventilation clearance
There must be a clearance of at least 200 mm in front of and behind the server
to ensure adequate ventilation of the subsystem.
Slot 1: PCIe Gen3 x1
(mechanical x4)
up to 167,65 mm length, low profile
Slot 2: PCIe Gen3 x4
(mechanical x4)
notched, up to 167,65 mm length, low profile
Slots 3, 4: PCIe Gen3
x8 (mechanical x8)
notched, up to 167,65 mm length, low profile
Slot notes In SAS configuration 1x PCI-Express occupied by
modular RAID controller.
HDD bay configuration up to 2x 3.5-inch non hot-plug HDD
up to 8x 2.5-inch HDDS/SSD
up to 4x 2.5-inch PCIe SSD and 4x 2.5-inch
HDD/SSD
Accessible drive bays 1x 3.5/1.6-inch for backup devices
Ultra Slim ODD
Upright operating
position (W x D x H)
193 mm x 438 mm x 360 mm (including feet)
Horizontal operating
position (W x D x H)
340 mm x 400 mm x 101 mm
Weight up to 11 kg
Weight notes Weight may vary depending on actual configuration
