Fujitsu PRIMERGY TX150 S2 Configuration Guide

SCSI On-board SCSI (ChA)
RAID Ctrl 0-Channel 128MB
PG-140D (On-board SCSI ChA)
(''1) Wide Backup Device: PG-DT502/PG-DTA102/PG-VX201
(''2)Backup Device requires 2 bays: PG-DTA102
Max: 4 HDDs HDD U320 10k 73GB non hot plug 1"
PG-HDH71K
HDD U320 15k 73GB non hot plug 1"
PG-HDH75K
RAID Ctrl 0-Channel 128MB
PG-140D HDD U320 10k 147GB non hot plug 1"
PG-HDH41K
*RAID is not applicable when SCSI controller connected.
One backup device can be mounted
Tape Drv DAT72 6x36GB Autoloader internal
SCSI Ctrl U160 w/SCSI Cable PG-DTA103
PG-129B
Tape Drv DAT72 36GB internal
PG-DT502
Tape Drv VXA-2 80GB
PG-VX201
*PRIMERGY SX10 is available for rack install type.
SCSI Ctrl U160
PG-128 SCSI Cable PRIMERGY SX10
PG-CBLS001(1.5m) PG-R1BC4
PG-CBLS002 (5m)
Eth. Ctrl 1000-BASE-T Cu Twist Pair Cable
PG-1892
*for PCI-X
Eth. Ctrl 1000-BASE-T Cu
PG-1852
*No AFT Support
<LAN Card for CTO>
Eth. Ctrl 1000-BASE-T Cu PGB1892
Eth. Ctrl 1000-BASE-T Cu PGB1852
SCSI Ctrl U160 w/SCSI Cable (PG-129B)
RAID
Product Name
Order
Lot
Wide (''1) / Backup Devices Connection (''2)
TX150 S2 Internal Backup Device ConnectionType of HDD connection
Type Interface
1
Product ID
1
LAN Card
SCSI Configuration
Internal HDD
Internal backup device
on board
SCSI Controller
PCI Bus
PCI Bus
PCI Bus
Internal backup device
PCI Bus
Connecting Internal HDD and Internal Backup Devices
Ultra320
Onboard
SCSI
for Internal HDD
PRIMERGY TX150 S2
On-board LAN

Fujitsu PRIMERGY TX150 S2 Specifications

General

Brand	Fujitsu
Model	PRIMERGY TX150 S2
Category	Server
Language	English
