Appendix: server specification
PCI-Slots
Drive bays
Operating Panel
PCI-Express 2.0 x4
(mech. x8)
2 x full height (1x long, 1x short)
PCI-Express 2.0 x8 2 x full height (1x notched, thus usable for x16 cards
operating in x8 mode)
PCI-Express x4 (mech.
x8)
1 x full height
PCI 1 x
Slot notes PCI slot: 32-bit / 33 MHz, 5 V; in SAS-configurations
1x PCI-Express slot is occupied by the modular
RAID-Controller
Hard disk bay
configuration
4x 3,5-inch, for SAS / SATA or 8x 2,5-inch for
SAS/SATA/SSD optional
Accessible drive bays 3 x 5.25/1.6-inch
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons On/off switch
NMI button
Reset button
Status LEDs System status (orange / yellow)
Identification (blue)
Hard disks access (green)
Power (orange / green)
Status LED at system
rear side:
System status (orange / yellow)
Identification (blue)
LAN connection (green)
LAN speed (green / yellow)
