TX200 S6 Operating Manual 65
5 Starting up and operation
V CAUTION!
Follow the safety instructions in chapter "Important information" on
page 31.
5.1 Access to the drives (floorstand model)
5.1.1 Access to the accessible drives
Figure 12: Removing the drive cover and snapping it into the hard disk drive cover
Ê Unlock the server (1).
Ê Remove the drive cover (2).
Ê Place the drive cover on the hard disk cover (3).
I Please note the following when operating with tape drives:
If the system is programmed to eject the media automatically, the
accessible drives must not be obstructed.
The drive cover is replaced and the server locked in the reverse order.
/
