100 Operating Manual TX2550 M5
Slots
Drive bays
Dimension/Weight
Standard
PCI-Express - Gen3 x16 3 x full height
PCI-Express - Gen3 x8 3 x full height
Expansion with riser module
PCI-Express - Gen3 x8 5 x full height
PCI-Express - Gen3 x16 2 x full height
PCI 32-Bit/33MHz (5V) 1 x full height 270 mm max. length
Slot notes Integrated RAID Controller occupies 1 x PCI
Express (not available when expander is
mounted)
Hard disk bay
configuration
Up to 32x hot plug 2.5-inch, or up to 12x hot plug 3.5-
inch
Up to 8x PCIe SSD
Accessible drive bays Up to 3x 1.6-inch drive bays for ODD or backup
Floorstand (W x D x H) 177 mm x 777 mm x 456 mm
Rack (W x D x H) 482.6 mm (bezel) / 448 mm (body) x 736 mm x
177 mm
Height unit rack 4 U
Mounting depth rack 745 mm
19" rack mount Yes
Weight 35 kg
Weight notes Weight may vary depending on actual configuration
Rack mounting kit Rack mounting kit as option
