TX2550 M5 Operating Manual 29
Product description
Note for connectors on OCP modules
The LAN connectors on the OCP modules are numbered in ascending order
from right to left beginning with “0”.
3.3.2 Controls and indicators on the server front
3.3.2.1 Controls on the front panel
Figure 7: Controls on the front panel module
Pos. Label Button Function
1 RESET Reset button
Reboots the system.
Press the reset button with a straightened
end of a paper clip.
V CAUTION!
Risk of data loss!
2 NMI NMI button
Used to troubleshoot software and device
driver errors.
Press the NMI button with a straightened end
of a paper clip.
V CAUTION!
Use this button only if directed to do so
by qualified certified maintenance
personnel!
