18 Operating Manual TX2550 M5
2.5-inch HDD/SSD model
Figure 1: Server front 2.5-inch HDD/SSD model - example TX2550 M5 (rack model)
Figure 2: Server front 2.5-inch HDD/SSD model - example TX2550 M5 (floorstand model)
Pos. Component
1 2.5-inch HDDs / SSDs / dummy modules
2 ODD / 5.25-inch dummy module
3ID card
4 8x 2.5-inch HDD extension box / 8x 2.5-inch PCIe SSD extension box
5 Front panel module
