Conditions for Mixed Batch Scanning
The following conditions apply when a mixed batch of documents with different paper sizes is scanned.
Make sure to test a few sheets first to check if the mixed batch of documents can be fed.
For details about scanning, refer to Scanning Documents with Different Widths (page 62).
ATTENTION
You cannot scan a mixed batch of documents with different paper weights/friction coefficients.
Paper Direction
Align the direction of the paper fiber with the feed direction.
Document Position
Load all documents covering the width of the pick roller (approx. 40 mm (1.57 in.) wide).
For a guideline for mixed batch scanning, refer to Combinations of Standard Paper Sizes in a Mixed Batch
(page 60) in Paper Size (page 60).
HINT
When the smallest document covers the width of the pick roller even when it is loaded towards one side
as shown in the image below, load documents aligned on one side. So that it prevents documents from
skewing when being fed.
How to Load Documents
59
