FUNAI T3A-A8182DB - Page 76

20070413 1-20-4 E3B40_43_44EL
C1655 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1656 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1657 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1658 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1659 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1660 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C1661 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1663 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1665 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1668 ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASDL470
C1673 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1674 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1675 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1676 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1677 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C1678 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1680 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V
CHD1JZ30F104
C1681 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C1687 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C1688 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1689 ELECTROLYTIC CAP. 0.33µF/50V M CE1JMASDLR33
C1690 PCB JUMPER D0.6-P5.0 JW5.0T
C1694 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C1695 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1696 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C1697 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
C1699 CHIP CERAMIC CAP.(1608) CH J 33pF/
50V
CHD1JJ3CH330
C1702 CHIP CERAMIC CAP.(1608) CH J 68pF/
50V
CHD1JJ3CH680
CONNECTORS
CN1502 FFC CONNECTOR 30PIN IMSA-9615S-
30A-PP-A or
JC96J30ER007
FFC CONNECTOR 30PIN 00 6232 030
006 800+
JC62G30UG026
CN1503 FFC CONNECTOR 30PIN IMSA-9615S-
30A-PP-A or
JC96J30ER007
FFC CONNECTOR 30PIN 00 6232 030
006 800+
JC62G30UG026
CN1504 FMN CONNECTOR SIDE 20P 20FMN-
STRK-A(LF)(SN)
JCFNG20JG022
CN1507 A AFV PCB ASSEMBLY E3B00ED E3B00AFV
CN1507 B,C AFV PCB ASSEMBLY E3B01BD E3B01AFV
DIODES
D301 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D510 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D520 LED(RED) 1254IT NPQZ0012541T
D555 LED MIE-534A2 or NPZZM1E534A2
LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D1501 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1502 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1503 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
Ref. No. Mark Description Part No.
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1505 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1506 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1507 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1512 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1513 PCB JUMPER D0.6-P5.0 JW5.0T
D1514 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1515 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1516 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1517 ZENER DIODE MTZJT-7733B or QDTB00MTZJ33
DIODE ZENER 33BSB-T26 or NDTB033BST26
ZENER DIODE DZ-33BSBT265 NDTB00DZ33BS
D1522 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1523 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1524 ZENER DIODE MTZJT-7710B or QDTB00MTZJ10
DIODE ZENER 10BSB-T26 or NDTB010BST26
ZENER DIODE DZ-10BSBT265 NDTB00DZ10BS
D1525 ZENER DIODE MTZJT-775.6C or QDTC0MTZJ5R6
DIODE ZENER 5V6BSC-T26 or NDTC5R6BST26
ZENER DIODE DZ-5.6BSCT265 NDTC0DZ5R6BS
D1526 ZENER DIODE MTZJT-7718B or QDTB00MTZJ18
DIODE ZENER 18BSB-T26 or NDTB018BST26
ZENER DIODE DZ-18BSBT265 NDTB00DZ18BS
D1527 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1528 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
DIODE ZENER 5V6BSB-T26 or NDTB5R6BST26
ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D1529 ZENER DIODE MTZJT-7710B or QDTB00MTZJ10
DIODE ZENER 10BSB-T26 or NDTB010BST26
ZENER DIODE DZ-10BSBT265 NDTB00DZ10BS
D1530 ZENER DIODE MTZJT-775.6C or QDTC0MTZJ5R6
DIODE ZENER 5V6BSC-T26 or NDTC5R6BST26
ZENER DIODE DZ-5.6BSCT265 NDTC0DZ5R6BS
D1531 ZENER DIODE MTZJT-777.5B or QDTB0MTZJ7R5
DIODE ZENER 7V5BSB-T26 or NDTB7R5BST26
ZENER DIODE DZ-7.5BSBT265 NDTB0DZ7R5BS
D1532 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1533 ZENER DIODE MTZJT-773.0B or QDTB0MTZJ3R0
DIODE ZENER 3V0BSB-T26 or NDTB3R0BST26
ZENER DIODE DZ-3.0BSBT265 NDTB0DZ3R0BS
D1534 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1535 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
Ref. No. Mark Description Part No.
