FUNAI T3A-A8182DB - Page 77

20070413 1-20-5 E3B40_43_44EL
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1536 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1537 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1539 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1540 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1541 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1542 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1543 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1544 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1545 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D1547 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1548 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1549 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1550 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1551 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1552 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1553 PCB JUMPER D0.6-P5.0 JW5.0T
D1563 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
DIODE SCHOTTKY SB140 or NDLZ00SB140S
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1564 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1565 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
D1567 ZENER DIODE MTZJT-778.2B or QDTB0MTZJ8R2
DIODE ZENER 8V2BSB-T26 or NDTB8R2BST26
ZENER DIODE DZ-8.2BSBT265 NDTB0DZ8R2BS
D1568 RECTIFIER DIODE 1N4005 or NDQZ001N4005
DIODE RECTIFIER 1N4005 or NDLZ01N4005S
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1569 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
ICS
IC301 IC Y/C/A LA71750EM-MPB-E QSZBA0RSY020
Ref. No. Mark Description Part No.
IC451 IC HIFI LA72648M-MPB-E QSZBA0RSY033
IC501 IC SYSCON M3776AMCH-AG7GP QSZAB0RHT153
IC612 VFD DRIVER/CONTROLLER IC PT6313-
S-TP(L) or
NSZBA0TG2007
VFD DRIVER IC SC16313G NSZBA0T0S005
IC1501 SUB MICON M306H7MC-C23FP#U0 QSZAA0RHT157
If IC1502 is R3112N211A-TR-F or BU4221G-TR, then C1505 is 0.015µF.
IC1502 VOLTAGE DETECT R3112N211A-TR-F or QSZBA0TRC026
RESET IC BU4221G-TR QSZBA0TRM102
C1505 CHIP CERAMIC CAP.(1608) B K 0.015µF/
50V
CHD1JK30B153
If IC1502 is PST3621NR, then C1505 is 0.15µF.
IC1502 SYSTEM RESET IC PST3621NR QSZBA0TMM162
C1505 CHIP CERAMIC CAP.(1608) B K 0.15µF/
25V
CHD1EK30B154
IC1506 IC OP AMP UTC4580 DIP-8 8PIN or NSZBA0S2H003
IC OP AMP RC4580IP NSZBA0STY173
IC1507 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC1508 IC OP AMP KIA4558P/P or NSZBA0SJY035
IC OP AMP UTC4558 NSZBA0S2H001
IC1509 IC INTERFACE HA118326ApF-E QSZBA0RHT051
COILS
L251 MICRO INDUCTOR 5.6µH-K-5FT LLARKBSTU5R6
L302 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L402 INDUCTOR 47µH-K-5FT LLARKBSTU470
L451 INDUCTOR 47µH-K-5FT LLARKBSTU470
L452 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L501 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L502 PCB JUMPER D0.6-P5.0 JW5.0T
L503 INDUCTOR 1.8µH-K-26T LLAXKATTU1R8
L1501 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1502 PCB JUMPER D0.6-P5.0 JW5.0T
L1504 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L1505 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L1506 INDUCTOR 100µH-K-5FT LLARKBSTU101
L1507 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1508 INDUCTOR 18µH-K-26T LLAXKATTU180
L1509 CHOKE COIL 22µH-K or LLBD00PKV021
CHOKE COIL 22µH-K LLBD00PKT002
L1510 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1511 PCB JUMPER D0.6-P5.0 JW5.0T
L1512 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1513 RADIAL TYPE CHOKE COIL CW68-
470K-841040NP or
LLBD00PKV023
CHOKE COIL 47µH or LLBD00PKV022
CHOKE COIL 47µH-K LLBD00PKT001
L1514 PCB JUMPER D0.6-P5.0 JW5.0T
L1516 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1601 BEAD CORE ASSEMBLY E3B91BD 1VSA15663
TRANSISTORS
Q302 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q401 CHIP TRANSISTOR RN1511(TE85R.F)
or
QQ2Z0RN1511F
CHIP TRANSISTOR FMG4A T148 QQ2Z000FMG4A
Q402 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
Ref. No. Mark Description Part No.
