20070413 1-20-15 E3B40_43_44EL
FRONT JACK CBA
R1120 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1123 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R1124 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1125 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1126 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1127 CARBON RES. 1/4W J 1.1k Ω RCX4JATZ0112
R1128 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R1129 CARBON RES. 1/6W J 100k Ω or RCX6JATZ0104
CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1130 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1131 CHIP RES. 1/10W F 18k Ω or RRXAFR5H1802
CHIP RES.(1608) 1/10W F 18k Ω or RRXAFR5Z1802
RES CHIP 1608 1/10W F 18.0k Ω RTW1802YF002
R1132 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1133 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R1134 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R1135 CHIP RES. 1/10W F 4.7k Ω or RRXAFR5H4701
CHIP RES.(1608) 1/10W F 4.7k Ω or RRXAFR5Z4701
RES CHIP 1608 1/10W F 4.70k Ω RTW4701YF002
R1136 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1138 CHIP RES. 1/10W J 470 Ω or RRXAJR5Z0471
RES CHIP 1608 1/10W J 470 Ω RRXA471YF002
R1139 CHIP RES. 1/10W J 6.8k Ω or RRXAJR5Z0682
RES CHIP 1608 1/10W J 6.8k Ω RRXA682YF002
R1140 CARBON RES. 1/6W J 560 Ω or RCX6JATZ0561
CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R1141 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R1142 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R1143 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R1144 CHIP RES. 1/10W F 10k Ω or RRXAFR5H1002
CHIP RES. 1/10W F 10k Ω or RRXAFR5Z1002
RES CHIP 1608 1/10W F 10.0k Ω RTW1002YF002
R1145 CHIP RES. 1/10W F 10k Ω or RRXAFR5H1002
CHIP RES. 1/10W F 10k Ω or RRXAFR5Z1002
RES CHIP 1608 1/10W F 10.0k Ω RTW1002YF002
R1146 CHIP RES. 1/10W F 15k Ω or RRXAFR5H1502
CHIP RES. 1/10W F 15k Ω or RRXAFR5Z1502
RES CHIP 1608 1/10W F 15.0k Ω RTW1502YF002
R1147 CHIP RES. 1/10W F 10k Ω or RRXAFR5H1002
CHIP RES. 1/10W F 10k Ω or RRXAFR5Z1002
RES CHIP 1608 1/10W F 10.0k Ω RTW1002YF002
R1148 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1149 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1150 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1151 CHIP RES. 1/10W F 100 Ω or RRXAFR5H1000
CHIP RES. 1/10W F 100 Ω or RRXAFR5Z1000
RES CHIP 1608 1/10W F 100 Ω RTW1000YF002
R1152 CHIP RES. 1/10W F 220 Ω or RRXAFR5H2200
CHIP RES.(1608) 1/10W F 220 Ω or RRXAFR5Z2200
RES CHIP 1608 1/10W F 220 Ω RTW2200YF002
R1153 CHIP RES. 1/10W F 1.5k Ω or RRXAFR5H1501
CHIP RES. 1/10W F 1.5k Ω or RRXAFR5Z1501
RES CHIP 1608 1/10W F 1.50k Ω RTW1501YF002
R1154 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1155 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R1157 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R1158 CHIP RES.(1608) 1/10W F 10 Ω or RRXAFR5H0100
Ref. No. Mark Description Part No.
CHIP RES. 1/10W F 10 Ω or RRXAFR5Z10R0
RES CHIP 1608 1/10W F 10 Ω RTW10R0YF002
R1159 CHIP RES. 1/10W J 33 Ω or RRXAJR5Z0330
RES CHIP 1608 1/10W J 33 Ω RRXA330YF002
R1160 CARBON RES. 1/6W J 220k Ω or RCX6JATZ0224
CARBON RES. 1/4W J 220k Ω RCX4JATZ0224
R1161 CARBON RES. 1/4W J 820k Ω RCX4JATZ0824
R1162 CARBON RES. 1/4W J 18 Ω RCX4JATZ0180
R1163 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1164 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R1165 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R1166 CHIP RES. 1/10W J 47k Ω or RRXAJR5Z0473
RES CHIP 1608 1/10W J 47k Ω RRXA473YF002
R1167 CHIP RES. 1/10W J 5.6k Ω or RRXAJR5Z0562
RES CHIP 1608 1/10W J 5.6k Ω RRXA562YF002
R1170 CARBON RES. 1/4W J 120 Ω RCX4JATZ0121
R1171 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R1172 CHIP RES. 1/10W J 10k Ω or RRXAJR5Z0103
RES CHIP 1608 1/10W J 10k Ω RRXA103YF002
R1174 CHIP RES. 1/10W F 330 Ω or RRXAFR5H3300
CHIP RES. 1/10W F 330 Ω or RRXAFR5Z3300
RES CHIP 1608 1/10W F 330 Ω RTW3300YF002
R1177 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
AC1001
!
AC CORD PE8G2CG9G0AB05 or WAE0172LW011
! AC CORD WITH A GND WIRE L0A0280-
010
WAE0172LTE08
B-5A HEAT SINK E2A00JD 1VM424636
B-5B POWER HEATSINK E3B90ED 1VM425352
CL1001 FFC CONNECTOR 30PIN IMSA-9615S-
30A-PP-A or
JC96J30ER007
FFC CONNECTOR 30PIN 00 6232 030
006 800+
JC62G30UG026
F1001! FUSE TIME RAG
TSD2A250VSVDEUC3CPSE or
PEG20B0W3002
! FUSE 50T020H 2.0A/250V PAGH20BHV202
FH1001 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
FH1002 FUSE HOLDER MSF-015 LF (B110) or XH01Z00LY002
FUSE HOLDER DFH-001 XH01Z00RP001
L-9N SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L-9O SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
T1001! TRANS POWER BCK-35-0341 or LTT3PE0XB006
! TRANS POWER 7710 LTTZPE0KT009
W2 FFC PW-MAIN 30P 30PIN/TL313MM WX1E3B00-002
W3 FFC AV-PW 30P 30PIN/TL90MM WX1E3B00-003
W4 FFC AV-SW 20P 20PIN/TL136MM WX1E3B00-004
W8 WIRE ASSEMBLY 4P AWG22/ 105MM WX1E4340-008
Ref. No. Mark Description Part No.
FRONT JACK CBA (PW/SW-B)
Consists of the following:
----------
CAPACITORS
C3006 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C3007 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
CONNECTOR
CN3001 FMN CONNECTOR SIDE 20P 20FMN-
STRK-A(LF)(SN)
JCFNG20JG022
DIODES
D3001 LED(RED) 1254IT NPQZ0012541T
D3002 LED(RED) 1254IT NPQZ0012541T
D3003 LED(AMBER YELLOW) LTL1CHKYKNN NPQZ1CHKYKNN
D3004 LED(BLUE) LTL1CHCBK2-F NPQ3L1CHCBK2
D3005 LED(GREEN) LTL1CHJGTNN NPQZ1CHJGTNN
Ref. No. Mark Description Part No.
