20070413 1-20-16 E3B40_43_44EL
SW CBA
REAR JACK CBA
D3008 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
DIODE ZENER 6V2BSB-T26 or NDTB6R2BST26
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D3009 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
DIODE ZENER 6V2BSB-T26 or NDTB6R2BST26
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D3010 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
DIODE ZENER 6V2BSB-T26 or NDTB6R2BST26
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
D3011 ZENER DIODE MTZJT-776.2B or QDTB0MTZJ6R2
DIODE ZENER 6V2BSB-T26 or NDTB6R2BST26
ZENER DIODE DZ-6.2BSBT265 NDTB0DZ6R2BS
RESISTORS
R3001 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R3002 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R3003 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R3004 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R3005 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R3006 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R3007 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R3008 CHIP RES. 1/10W J 220 Ω or RRXAJR5Z0221
RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
R3010 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R3011 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R3013 CHIP RES. 1/10W J 300 Ω or RRXAJR5Z0301
RES CHIP 1608 1/10W J 300 Ω RRXA301YF002
R3014 CHIP RES. 1/10W J 360 Ω or RRXAJR5Z0361
RES CHIP 1608 1/10W J 360 Ω RRXA361YF002
R3015 CHIP RES. 1/10W J 620 Ω or RRXAJR5Z0621
RES CHIP 1608 1/10W J 620 Ω RRXA621YF002
R3016 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R3017 CHIP RES. 1/10W J 2.2k Ω or RRXAJR5Z0222
RES CHIP 1608 1/10W J 2.2k Ω RRXA222YF002
R3018 CHIP RES. 1/10W J 4.7k Ω or RRXAJR5Z0472
RES CHIP 1608 1/10W J 4.7k Ω RRXA472YF002
R3022 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R3023 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R3026 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R3029 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R3032 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R3035 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R3038 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
SWITCHES
SW3001 SWITCH TACT KSM0634B PB(F) or SST0101HH036
SWITCH TACT SKHHLRA010 SST0101AL071
SW3002 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3003 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3004 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3005 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
Ref. No. Mark Description Part No.
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3006 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3007 TACT SWITCH SKQSAF001A or SST0101AL041
TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
MISCELLANEOUS
B-9A BUSH LED(F) H3700UD 0VM409508
B-9B BUSH LED(F) H3700UD 0VM409508
B-9C BUSH LED(F) H3700UD 0VM409508
B-9D BUSH LED(F) H3700UD 0VM409508
B-9E BUSH LED(F) H3700UD 0VM409508
JK3001 RCA JACK(YELLOW) MTJ-032-05B-
20(B110)
JXRL010LY135
JK3002 RCA JACK(WHITE) MTJ-032-05B-
22(B110)
JXRL010LY136
JK3003 RCA JACK(RED) MTJ-032-05A-21(B110) JYRL010LY029
JK3004 MINI DIN SOCKET MDC1-34-020 or JXEL040RP003
S TYPE JACK DIN-405 JXEL040YUQ02
W7 WIRE ASSEMBLY FLAT CABLE 5P
AWG26#2651/P2.0/120
WX1E3B00-014
Ref. No. Mark Description Part No.
SW CBA (PW/SW-C)
Consists of the following:
----------
DIODE
D3006 LED(RED) 1254IT NPQZ0012541T
RESISTORS
R3021 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
SWITCHES
SW3002 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3003 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3004 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3005 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3006 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3007 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH TC-1104(H=9.5) SST0101DNG01
SW3008 TACT SWITCH SKQSAF001A SST0101AL041
SW3009 TACT SWITCH SKQSAF001A SST0101AL041
SW3010 TACT SWITCH SKQSAF001A SST0101AL041
MISCELLANEOUS
B-9F BUSH LED(F) H3700UD 0VM409508
Ref. No. Mark Description Part No.
REAR JACK CBA (PW/SW-D)
Consists of the following:
----------
CAPACITORS
C2001 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C2002 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C2003 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2004 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2005 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2006 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2007 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C2008 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C2009 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C2010 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
Ref. No. Mark Description Part No.
