FUNAI T3A-A8182DB - Page 89

20070413 1-20-17 E3B40_43_44EL
AFV CBA
C2011 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
C2012 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C2013 CHIP CERAMIC CAP.(1608) B K 1000pF/
50V
CHD1JK30B102
DIODES
D2001 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2002 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2003 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2004 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2005 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2006 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2007 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2008 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2009 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
D2010 ZENER DIODE MTZJT-7711A or QDTA00MTZJ11
DIODE ZENER 11BSA-T26 or NDTA011BST26
ZENER DIODE DZ-11BSAT265 NDTA00DZ11BS
COIL
L2003 BEAD CORE ASSEMBLY E3B91BD 1VSA15664
TRANSISTORS
Q2001 TRANSISTOR KTA-1266-GR-AT/P or NQS4KTA1266P
TRANSISTOR 2SA1015-GR(TE2 F T) QQS12SA1015F
Q2002 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
Q2003 TRANSISTOR KTC3199-Y-AT/P or NQSYKTC3199P
TRANSISTOR KTC3199-GR-AT/P or NQS4KTC3199P
TRANSISTOR 2SC1815-Y(TE2 F T) or QQSY2SC1815F
TRANSISTOR 2SC1815-GR(TE2 F T) QQS12SC1815F
RESISTORS
R2001 CARBON RES. 1/6W J 680 Ω or RCX6JATZ0681
CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R2002 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R2003 CARBON RES. 1/4W J 75 Ω RCX4JATZ0750
R2005 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2006 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2007 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R2008 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R2009 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2010 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2011 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R2012 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R2013 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
Ref. No. Mark Description Part No.
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R2014 CHIP RES. 1/10W J 75 Ω or RRXAJR5Z0750
RES CHIP 1608 1/10W J 75 Ω RRXA750YF002
R3021 RES CHIP 1608 1/10W J 220 Ω RRXA221YF002
MISCELLANEOUS
B-24 21P EARTH PLATE E7B20ED 1VM423185
JK2001 RGB CONNECTOR MRC-021V-03
ABS(B11
JXGL210LY006
JW2001 FLAT CABLE 15P AWG26#2651/P2.0/70 WX1E7B20-002
Ref. No. Mark Description Part No.
A
B,C
AFV CBA
AFV CBA
Consists of the following:
1VSA15651
1VSA15656
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C4 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C5 CHIP CERAMIC CAP.(1608) CH J 22pF/
50V
CHD1JJ3CH220
C6 CHIP CERAMIC CAP. CH J 56pF/50V CHD1JJ3CH560
C7 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C8 CHIP CERAMIC CAP. CH C 3pF/50V or CHD1JC3CH3R0
CHIP CERAMIC CAP. CJ C 3pF/50V or CHD1JC3CJ3R0
CHIP CERAMIC CAP. CH D 3pF/50V CHD1JD3CH3R0
C11 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C12 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C13 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C14 CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C15 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C16 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C17 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C20 ELECTROLYTIC CAP. 3.3µF/50V M H7 CE1JMASSL3R3
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/
50V or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/
25V
CHD1EZ30F104
C22 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C24 ELECTROLYTIC CAP. 0.22µF/50V M H7 CE1JMASSLR22
C27 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
CONNECTOR
CN1 ANGLE PIN HEADER 9P IMSA-6029B-1-
09Z003-
JTED009ER045
DIODES
D2 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
DIODE SWITCHING 1N4148-F0021 or NDTZ01N4148F
SWITCHING DIODE 1N4148M NDTZ01N4148M
ICS
IC1 A IC AUDIO PROCESSOR MSP3407G-
QG-B8-V3
NSZBA0SP3004
IC1 B,C IC AUDIO PROCESSOR MSP3417G-
QG-B8-V3
NSZBA0SP3005
COILS
L1 INDUCTOR 10µH-K-5FT LLARKBSTU100
L2 PCB JUMPER D0.6-P5.0 JW5.0T
L3 INDUCTOR 18µH-K-26T LLAXKATTU180
L4 INDUCTOR 10µH-K-5FT LLARKBSTU100
Ref. No. Mark Description Part No.
