FUNAI T3A-A8182DB - Page 90

20070413 1-20-18 E3B40_43_44EL
ATA CBA
RESISTORS
R1 CHIP RES. 1/10W J 1k Ω or RRXAJR5Z0102
RES CHIP 1608 1/10W J 1.0k Ω RRXA102YF002
R4 CHIP RES. 1/10W J 120k Ω or RRXAJR5Z0124
RES CHIP 1608 1/10W J 120k Ω RRXA124YF002
R5 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
R6 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R6 RES CHIP 1608 1/10W J 0 Ω RRXA000YF002
MISCELLANEOUS
X1 XTAL 18.432MHz FXD186LLN001
X1 RESONATOR XTAL 186 910A018432-
1030300
FXD186LXGE01
Ref. No. Mark Description Part No.
ATA C BA
Consists of the following:
1VSA15986
CONNECTORS
CN3001 IDC SOCKET 40PIN VT YKF43-0025 JCYKC40JC002
CN3001 CONNECTOR PRINT MES IMSA-9353S-
40B-GT
JC93400ER001
CN3002 FPC/FFC CONNECTOR(40PIN) FH12-
40S-0.5SH(89)
JCFHD40HQ007
Ref. No. Mark Description Part No.
