4.2 Specifications
Driver complement: 8” cone driver
1” compression driver
Frequency response: 95Hz – 19kHz
Dispersion: 90° x 70°
Sensitivity: 98dB spl for 1W at 1m
AES power: 100W (av)
Maximum calculated spl* 118dB spl rms, 124dB spl peak
(* See Appendix C)
Max long-term rms voltage: 28.2rms
Maximum peak voltage: 56.4vpk
Recommended amp power: 200-400W into 8ohms/400-800W into 4ohms with suitable limiters
Nominal impedance: 8 ohms
Connectors: 2 x NL4 Speakon or Phoenix installation connector
Fittings: 2 x M6 yoke mounting bushes (one per side)
2 x M6 wall bracket bushes on rear
Weight: 5.2kg (11.5lb)
Dimensions
Fig 4.2-1 (all dimensions in millimetres and feet & inches)
