3. SETTING AND ADJUSTMENT
3-21
3.7.3 Choosing External Radar (image source)
Select the external radar to use in the dual radar display.
1. Open the INITIALIZE menu.
2. Press the [3] key to show the SCANNER menu.
3. Select 9 [DUAL RADAR] and push the left button.
1BACK
2 DUAL RADAR
OFF/ COMBINE
3 COMBINE MODE
OWN/EXT
4 COMBINE SECTOR
START 000°
ANGLE 000°
5 COMBINE RANGE
START 00.00NM
LENGTH 00.00NM
6 EXT RADAR
1/2/3/4
[DUAL
RADAR]
4. Select 6 EXT RADAR and push the left button.
5. Select
desired radar no. and push the left button.
Only the numbers of connected radars are valid. Radar no. is set on the Installation Setting
menu.
6. Press the [MENU] key to close the menu.
