SYSTEM CONFIGURATION
100/110/115/
220/230 VAC
1 φ, 50/60 Hz
Network Sounder
DFF3
12-24 VDC
Low
Freq.
Transducer
High
Freq.
Transducer
Rectifier
PR-62
Speed/Temperature Sensor
ST-02MSB
ST-02PSB
Temperature Sensor
T-02MTB
T-02MSB
T-03MSB
DFF3
NETWORK SOUNDER
ST-BY
* HUB-100 (For NavNet/NavNet vx2)
HUB-101 (For NavNet 3D/TZtouch)
NavNet Series
HUB*
