Parts List
This equipment contains complex modules in which fault diagnosis and repair down to
component level are not practical (IMO A.694(17)/8.3.1. Only some discrete components
are used. FURUNO Electric Co., Ltd. believes identifying these components is of no value
for shipboard maintenance; therefore, they are not listed in the manual. Major modules
can be located on the parts location photo on page AP-4.
F U R U N O
Model FA-100
Unit
TRANSPONDER UNIT
ELECTRICAL PARTS LIST
2002-June Blk.No.
SYMBOL TYPE CODE No. REMARKS SHIPPABLE
ASSEMBLY
PRINTED CIRCUIT BOARD
24P0026, LKY2 005-950-780 X
24P0025, OCN2 005-950-790 X
24P0024, MOT2 005-950-800 X
24P0015, MPB 005-950-880 X
ASSEMBLY
RX1 005-952-240 24P0010A X
RX2 005-952-250 24P0010B X
EXCT 005-952-260 24P0012 X
DSC 005-952-270 24P0013 X
PA 005-952-280 24P0014 X
PWX 005-952-290 24P0016 X
FRONT PANEL ASSEMBLY
FA-100 005-952-310 X
FILTER ASSEMBLY
FA-100 005-952-230 X
BREAKER
BK1 TBC5101-01-1211 000-119-400
GPS ASSEMBLY
GN-7N5A-N 005-952-860
To Next Page
