Furuno FCV-295 - System Configuration

vi
SYSTEM CONFIGURATION
Basic configuration is shown below with solid line.
Low
Freq.
Transducer
High
Freq.
Transducer
Navigation
Equipment
DISPLAY UNIT
CV-295
Power
12-24 VDC
Rectifier
PR-62
100/110/115/
220/230 VAC
1
φ , 50/60 Hz
Water Temp. Sensor
T-02MSB, etc.
Water Temp.+Speed Sensor
ST-02MSB, etc.
