1. OPERATION AND CONTROLS OVERVIEW
1-6
1.7.2 How to set up pages
The FI-70 is capable of displaying seven pages of category information.
The procedure below outlines how to set up a page.
1. Press the Menu/Back key to display the main menu.
2. Press the right software key to scroll down the menu and highlight [Disp Config],
then press the function key.
3. Press the software keys to select the appropriate page. The page number is
displayed at the center of the screen for three seconds after each page change.
4. Press the function key to display the category selection screen.
5. Press the software keys to select the appropriate category to display, then press
the function key. The current selection is highlighted with a blue box.
6. Press the function key to set the selected category (and screen if applicable) for
the selected page. Some categories have several display screens available. See
chapter 2 for further details on available screens for the selected category.
7. If the category selected at step 5 was [Graph], set the graph data display as
follows:
1) Press the software keys to select [1Graph] or [2Graphs] as appropriate, then
press the function key. For this example, [2Graphs] is chosen.
2) Press the software keys to select the graph to setup, then press the function
key.
50
º
AWA
T
Select a page to setup.
Ent NextPrev
50
º
AWA
A
AIS
㻺㼑㼤㼠
Select screen category.
Wind
l0
:00
12
NM
Graph1: Depth
A. Temp
Select Graph
Graph2:
Done
