. INSTA ATION
-4
How to attach errite core
To suppress RF interference that can cause abnormal operation of the transceiver, at-
tach the supplied three ferrite cores to the Accessory Cable/Power Cable and Exten-
sion Cable, then snap its two halves together, as shown in the illustration below.
Attach each ferrite core as close as possible to the transceiver body, as shown. Final-
ly, wind some plastic tape around each ferrite core, to prevent vibration from causing
the two halves to split apart.
421
