APPENDIX 1 CHANNEL ASSIGNMENTS, MENU TREE
AP-5
Menu Tree (default settings shown in bold italic)
DSC menu
Setup menu
CALL/
MENU
key
DSC
Menu
Individual (Select, New ID)
Group (Select, Manual)
All Ships (Safety, Urgency)
POS Request (Select, Manual)
POS Report (Select, Manual)
Distress Alert MSG (Nature, POS/TM)
Auto POS Polling (Activation, Select Address)
DSC Log
DSC Test (Select, Manual)
Transmitted Log
Distress Log
Other Call Log
Log Delete
Transmitted Log
Distress Log
Other Call Log
CALL/
MENU
key
(Long push)
Setup
Menu
General
Setup
Contrast (0 - 31, 10)
Time Offset (+12:00 to -12:00, 00:00)
Time Area (UTC, Local)
Time Display (12 hour, 24 hour)
Unit of Measure
Magnetic (True, Magnetic)
Position Input (Enter position, time)
Key Beep (High, Level 1 - Level 6, Off)
Tone Control
Fog Frequency (200 - 850 Hz (50 Hz steps), 400 Hz)
Station Name
(Name Station.)
Soft Keys
Calendar
Speed (KTS: Knots, MPH: Mile/Hour,
KMH: Kilo-Meter/Hour)
Distance (NM: Nautical Mile,
SM: Statute Mile, KM: Kilo-Meter)
Control Range (Bass, Treble)
Tone Level (-6 to +6, 0)
Select Unit
Unit Name
Number of Soft Keys (3 - 10)
Key Assignment
Key Timer (1 - 10sec; 5sec)
Key 1 (None, DIMMER,
SCAN, DW, IC, PA/FOG,
PRESET, SCRAMBLER)
Key 2 (Same choices as
Key 1, no default setting.)
Key 3 (Same choices as
Key 1, no default setting.)
Calendar (Enter date, time.)
Update (Automatic, Manual)
(Continued on
Next page)
Daily Test
VOX Function
Save Function
Pin Code
Pairing
Bluetooth
