Furuno FV-110 - Chapter 5 Configuration; 5.1 Introduction to the Built-in Web Interface

5-1
Chapter 5
Configuration
5
This chapter is organised in the following sections:
• Introduction to the built-in web interface
• Calibration
• Configuration with the web interface
• Keypad and menus of the ACU
• SNMP support
5.1 Introduction to the built-in web interface
5.1.1 Overview
Use the built-in web interface (installation of software is not necessary) of the FV-110
ACU to make a full configuration of the FV-110 with the correct VMU, the satellite
positions you intend to use and other parameters. You can use a standard Internet
browser.
For quick start instructions see Calibration on page 5-3.
5.1.2 Connecting to the web interface
To connect to the web interface of the ACU do as follows:
1. Power up the FV-110 system, i.e. switch on the ACU. Wait until the LEDs on the front
plate of the ACU show that the system is ready to be configured.
• Power LED: Green
• Logon LED: Off
• Fail/Pass LED: Flashing green, during power-on self test, after that steady green.
2. Connect a PC to LAN interface 3 (Service port, standard Ethernet) of the ACU or to
the front LAN connector of the ACU.
Important
The FV-110 system is not designed to be connected directly to the Internet.
It must be located behind a dedicated network security device such as a
firewall.
If any ports of the FV-110 are exposed to the Internet you must change the
default passwords as anyone with access and malicious intent can render the
FV-110 inoperable.
