Configuration with the web interface
5-20
•Safe Mode (error, followed by an error description)
• Service switch (service switch in ADU activated)
•Ready (waiting for data from the modem or no satellite profile selected)
• Pointing antenna (locating the satellite)
• Acquiring signal (acquiring the satellite signal)
• Tracking (tracks the current satellite)
•Lineup (line up is activated)
• Azimuth calibration
• TX cable calibration
•Test
•Not ready (waiting for input from GNSS, e.g. GPS)
• Not ready: Initializing
• Not ready: Need pos
• Blocking zone (antenna is pointing into a blocking zone)
•No TX zone (antenna is pointing in a no TX zone; TX is off
Sections on the Dashboard
FV-110 parameter Description
GNSS position Current position of the vessel, reported by the GPS module
Vessel heading Ship’s heading in degrees with reference to North, provided by
the ship’s gyro.
Satellite profile Name of the currently active satellite profile.
Satellite position Position of the satellite selected in Satellite profile.
RX polarisation Horizontal or vertical.
TX polarisation
a
Co-pol or X-pol, auto-selected by VSAT modem
RX RF frequency
a
Ku band receiving frequency, auto-selected by VSAT modem
LNB Lo
frequency
a
Auto-selected by VSAT modem
TX RF frequency
a
Auto-selected by VSAT modem
BUC Lo frequency 12.8 GHz (system parameter)
Tracking RF
frequency
Current RF tracking frequency.
Table 5-9: Web interface, DASHBOARD, FV-110 parameters
