Configuration with the web interface
5-21
ACU part name,
Antenna part name,
ACU serial
number, Antenna
serial number,
Software version
Part names, serial numbers for ACU and antenna, software
version of the FV-110.
a. Can be altered when using a generic modem profile.
MODEM
parameter
Description
Model VSAT modem name, entered in SETTINGS > Modem profiles.
Signal level Current input signal level from the VSAT modem.
iDirect openAMIP modem: 0-500(pwr), delivered by the
connected modem. For values <250 the antenna searches for a new
signal.
Other modem: Signal level in dB.
RX IF frequency Read out from VMU.
TX IF frequency Read out from VMU.
TX allowed On or Off. Indicates if the VSAT modem supplies the 10 MHz
reference signal on its TX connector (On) and if an iDirect
OpenAMIP modem indicates modem Locked and Tx ON in the
OpenAMIP message L (L 1 1).
Table 5-10: Web interface, DASHBOARD, VSAT MODEM parameter
POINTING
parameter
Description
Azimuth relative Current value for azimuth, relative to the vessel heading.
Elevation relative Current value for elevation, relative to the vessel.
Polarisation skew Current value for polarisation skew.
Table 5-11: Web interface, DASHBOARD, POINTING parameter
TX parameter Description
BUC TX On or Off. Shows if the FV-110 has enabled the BUC or not. It is
the same TX ON/TX OFF as shown in the display of the ACU,
see ACU display and keypad on page 5-46.
Table 5-12: Web interface, DASHBOARD, TX parameter
FV-110 parameter Description
Table 5-9: Web interface, DASHBOARD, FV-110 parameters (Continued)
