Configuration with the web interface
5-35
Processing the statistics report in a spreadsheet application
The statistics report is in a data format that can be imported into spreadsheet applications,
e.g. Microsoft Excel, for further processing.
1. Save the zipped file to your computer and extract the text file. The file name contains
the identification of the system (example: adu-acu3_stat_20111021110901_day.csv).
2. Open the spreadsheet application, for example Microsoft Excel. On the tab Data click
the tab Import from text. Import the unzipped text file and follow the instructions in
the wizard. When asked about the delimiter, select ‘comma’.
The following figure shows an example of a statistics report in MS Excel 2007.
Remote syslog
You can set up the antenna to send each syslog message to a syslog server to advise the
system administrator of the current status of the antenna.
To set up sending syslog messages to a syslog server, do as follows:
1. Select SETTINGS > Reporting.
2. In the section Remote syslog select On to enable remote syslog (default: Off).
3. Enter the IP address of the syslog server to which the syslog messages will be sent.
4. Click Apply.
SNMP traps
SNMP traps, or notifications, are network packets which advise the system administrator
about significant events in the antenna, e.g. alarms and system error messages. They are
generated by the antenna and can be sent automatically to an SNMP trap
receiver/manager. The event time is UTC time.
To set up reporting SNMP traps to an SNMP server, do as follows:
1. Select SETTINGS > Reporting.
2. In the section SNMP traps select On to enable sending of SNMP traps (default: Off).
3. Enter the IP address of the SNMP trap receiver/manager to which the SNMP traps will
be sent.
4. Enter the Community name. This is the name of the SNMP trap receiver/manager.
This is needed for authentication of the SNMP trap request.
5. Click Apply.
