Furuno MU-201C - Page 10

3
Cosmetic cap
Hex bolt
(M6x25)
Hanger L
M10 bolts for fixing
(Dockyard supply)
Hanger stay
Hanger R
Flat washer (M10)
Spring washer (M10)
Hex bolt
(M10x30)
Hole plug
Plastic rivet
To remove this, insert fingernail in groove.
Desktop mounting
The optional handgrip assy. (Type: FP03-09840, Code No.: 008-535-570) is available for
the desktop mount display unit.
Handgrip
Wave washer
Rosette washer
Oval countersunk head screw
