4. POINTS, BOUNDARIES
4-26
6. Use the software keyboard to enter new radius, then tap [].
7. To change the name, tap [Name].
8. Enter new name, then tap [].
9. To change the comment, tap [Comment].
10. Enter new comment, then tap [].
11. To change the color, tap [Color].
12. Tap color desired, tap [], then tap [<] on the title bar to go back one layer in the
menu.
13. To change line type, tap [Contour].
14. Tap line type desired, tap [], then tap [<] on the title bar to go back one layer in
the menu.
15. To change boundary transparency, tap [Transparency].
16. Adjust the slider bar at [Transparency], or enter desired value with the software
keyboard at [Transparency].
17. Tap the close button on the title bar to finish.
4.15.6 How to add a point to a boundary
You can add points to a line or area type boundary.
1. Tap the boundary to which you want to add a point(s).
2. Tap [Edit Points] on the pop-up menu.
Icons appear on the boundary.
3. Tap the position where to add a point, and an icon appears at that position. If nec-
essary, drag the icon to reposition the new point.
4. Tap [End Boundary] at the top-right corner to finish.
4.15.7 How to move a point on a boundary
You can move a point on a boundary by two methods, on-screen and on the [Bound-
aries] list.
How to move an on-screen point
1. Tap the boundary to which you want to add a point(s).
2. Tap [Edit Points] on the pop-up menu.
Icons appear on the boundary.
3. For area or line type boundary: Drag the icon to new location.
For circle boundary: Drag the “resize” or “relocate” icon to new location.
4. Tap [End Boundary] at the top-right corner to finish.
How to move a point from the Edit screen
1. Tap the boundary to which you want to add a point(s).
2. Tap [Edit] on the pop-up menu to show the Edit menu.
3. Tap [Edit Points] to show the [Boundary Detail] screen.
4. Tap the point whose position you want to change to show the [Position] screen.
5. Tap [Lat Lon] to show the software keyboard.
